Moccasin Industrial Sewing Machine For Environmentally Friendly Shoes Making machine
Moccasin Industrial Sewing Machine For Environmentally Friendly Shoes Making machine
Moccasin sewing machine for environmentally friendly shoes
1.Excellent structure design and operation is simple and efficient.
2.The speed can be adjusted by means of an electronic governor motor.
3.All parts were manufactured by HAAS CNC machines, high precision machining parts.
4.In the event of an emergency, the machine stops running to prevent damage when the threads are jammed.
|
Technical parameter: |
|
| Model | DF-747H |
|
Sewing speed |
Stepless speed regulating |
|
Sewing thickness |
3mm |
|
Stitch length |
6-8mm |
|
Sewing thread |
Woven wire(1-1.2) |
|
Sewing needle |
DY-100(200-300#) |
|
Motor |
750W/ 220V one-phase 50-60hz |
|
Net weight |
210Kg |
|
Domestic packing gross weight |
250Kg |
|
Domestic packing parameter |
103*86*152 ( L*W*H ) cm |
|
Exportation packing gross weight |
290Kg |
|
Exportation packing parameter |
103*88*159 ( L*W*H ) cm |
|
Characteristics: |
|
|
1.Suitable for upper and sole sewing of green footwear |
|
|
2. All parts were manufactured by HAAS CNC machines, high precision machining parts. |
|
|
3. Presser foot and advanced needle agencies by pneumatic system to control realization. |
|
|
4. Adopt servo motor, speed can be flexible, stop the needle position by computer control. |
|
